We've compiled a list of specs & changes in all of the model years of the 6.7L Powerstroke. Each model year has proved that Ford is always learning from the last & developing the best powertrain combinations for its consumer.
|
11-12 6.L Powerstroke
|
13-14 6.7L Powerstroke
|
15-16 6.7L Powerstroke
|
17-18 6.7L Powerstroke
|
|
|
Peak HP/TQ (at crank) |
400hp/ 800ft-lb |
400hp/ 800ft-lb |
440hp/ 860ft-lb |
440hp/ 925ft-lb |
|
Factory Turbo |
Garrett GT32 single sequential turbocharger (SST) which features a dual compressor and single turbine setup affixed to a common shaft Air-to-Water Intercooler |
Garrett GT32 single sequential turbocharger (SST) which features a dual compressor and single turbine setup affixed to a common shaft Air-to-Water Intercooler |
Single Garrett GT37 variable geometry turbocharger (VGT) Air-to-Water Intercooler |
Single Garrett GT37 variable geometry turbocharger (VGT) Air-to-Water Intercooler |
|
Fuel System |
Direct injection, 30,000 psi high-pressure common rail 19mm Piezo actuated injectors with 8 hole nozzles Bosch CP4.2 high-pressure injection pump |
Direct injection, 30,000 psi high-pressure common rail 19mm Piezo actuated injectors with 8 hole nozzles Bosch CP4.2 high-pressure injection pump |
Direct injection, 30,000 psi high-pressure common rail 19mm Piezo actuated injectors with 8 hole nozzles Bosch CP4.2 high-pressure injection pump |
Direct injection, 30,000 psi high-pressure common rail 19mm Piezo actuated injectors with 8 hole nozzles Bosch CP4.2 high-pressure injection pump |
|
Transmission |
6R140 Torqshift 6-speed Automatic with Tow/Haul Mode Adaptive Memory |
6R140 Torqshift 6-speed Automatic with Tow/Haul Mode Adaptive Memory |
6R140 Torqshift 6-speed Automatic with Tow/Haul Mode Adaptive Memory Decreased clutch counts in overdrive |
6R140 Torqshift 6-speed Automatic with Tow/Haul Mode Adaptive Memory |
|
Additional Changes |
PCM changed |
PCM changed Larger wrist pin design Increased fuel output on the CP4.2 |
PCM changed New Body Style introduced Larger connecting rods design introduced in 2017 Job2 Secondary transmission cooler integrated into the primary cooler Eliminated plastic intercooler piping & went to silicone F250/F350 Limited introduced in 2018 |
If we missed anything, let us know in the comments below.
